Hull & Deck

'Frisco' has a solid hand laid fiberglass construction for the hull and cored deck, with two tone non skid fiberglass decks (no teak decks) and varnished teak trim.

• Hull colour is original white gelcoat with flag blue waterline & cove stripe
• Antifouling (Micron CSC "2023" over Interprotect)
• Vetus Bow Thruster
• Sunbrella Cockpit dodger w/bimini, connector piece and enclosure
• Maxwell Nilsson 1000 windless (both chain and rode)
• Rocna 75 lb primary anchor with  250’ 3/8” chain
• Saltwater wash-down on foredeck
• Double lifelines (new in 2003)
• Dinghy Davis with Solar Panels Mounted Above (160 W)
• Boarding gates port and starboard
• Stainless steel dinghy davits
• Stainless steel, rail mounted folding swim/boarding ladder
• (5) Teak dorade boxes w/ s/s vents in lieu of standard fiberglass,
• (6) Stainless steel hatches w/screens
• (9) Hood s/s opening ports w/screens.
• Stainless steel genoa and staysail tracks
• Stainless steel steering pedestal
• Varnished teak handrails
• Stainless steel safety rails at mast base port & starboard
• Non-skid on deck and cabin top

Accommodations

'Frisco' sleeps up to six in two private staterooms and a Pilot berth the main salon with 6'3" headroom throughout. Espar diesel heating throughout interior.

FORWARD STATEROOM: There is standing headroom and a vee berth(with filler) bed, plentiful drawers and lockers (some cedar lined), an overhead hatch and two opening ports for excellent ventilation, 120VAC outlets and reading lights. Access to a huge chain locker forward. Furnace outlet.

The Head is aft to port and features solid countertop, stainless sink, pressure hot and cold water, foot activated water pump, a mirrored vanity. Manual toilet is fitted with a “Y” valve for offshore discharge. In addition, hand diaphragm pump for offshore discharge from holding tank.  There is a separate shower room with seat with furnace outlet and heated towel racks. Plentiful linen and toiletry lockers. Across from the head is a large hanging locker.

MAIN SALON: The main salon features a U-shaped settee with custom teak dining table(three sizes – coffee table, standard table for six or large table seating 10). To starboard is a full-length settee with convertible upper pilot berth There are outboard lockers with beautiful louvered teak doors both port and starboard, a large cedar hanging locker, a wet locker, with more storage under and behind the settee and dinette. Furnace Outlet.

AFT STATEROOM: There is standing headroom, a double bed to port, a hanging locker, drawers, several additional storage spaces, an overhead hatch and two opening ports for ventilation, ceiling fan, reading lights, 120VAC outlets and a furnace outlet.

NAV STATION: The navigator sits on an upholstered swing out stool in front of a large chart table, substantial chart storage under table, electronics flush mounted within easy reach, master electrical panel is immediately to the right with circuit breakers and monitors for electrical systems, shore power, etc.

Water Maker - 12v PUR 40E (1.5 GPH)

Galley

The large U shaped galley is next aft to port, with a double stainless steel sinks, three burner propane stove with oven, plus refrigeration and freezer with access both from the countertop. Fridge portion also has door access. The galley and galley storage areas have been very nicely detailed with racks for mugs and glasses, the galley shelves have been sized and fitted for standard yacht dishes.

• Sea Frost refrigerator/freezer; (2 plates fridge: 1 12v-water cooled & engine drive)
• Force 10 propane 3 Burner stove/oven
• Pressure and manual hot & cold-water Manual water foot pump in head
• Deep double S/S sink with extended countertop
• Small PUR 12v Model 40E Watermaker

Electronics/Navigation Equipment

Nav Station

Raymarine Pathfinder R70 Radar with mast mounted Radome

Raytheon ST 60 Knotmeter

Raymarine ST 60 Wind Machine

Raymarine ST60 Depthsounder

Raymarine ST7002 Autopilot

Furuno GPS/WAAS Navigator

JVC Stereo

ICOM IC-M604 VHF

ICOM IC-M710 SSB

Pactor Modem PTC-IIpro

Raymarine AIS

Helm

Raymarine Hybrid Touch Multifunction Display in Binnacle NavPod

Raymarine Radome on Stern Post

Electric Genoa Furling Switch

Kill Switch for Electric Winches

Reset Switch for Electric Winches

ICOM Remote VHF Mic

Vetus Bow Thruster 150mm Dia, 55 kgf

Raymarine ST7002 Autopilot Control (New Evolution Raymarine control in box}

6” Ritchie Binnacle Compass

Port Side Cockpit Bulkhead

Raymarine ST60+ Apparent Wind

3 Raymarine i70 MFD’s (2023)

Electrical

• Battery Capacity Doubled to 800Ah
• Four 200Ah AGM batteries (2018)
• 80 amp Balmar alternator on engine (2022)
• 1000 watt Heart inverter with automatic battery charger
• Wired for European(disconnected) and North American(connected) Shorepower

Sails and Rigging

• Schaffer Gamma Roller Furling Boom (2018)
• Mack Sails full batten mainsail (2018)
• Bamar EJF1 electric genoa furling system (2018)
• North Sails 110% genoa (2014)
• Convertible Cutter Stay with Hank on Staysail
• Storm Jib(orange color)
• Storm Trysail (orange colour) with separate mast mounted track
• SS Shroud Chain Plates replaced  (2020)
• SS Bow Chain Plate replaced (2023)
• SS Turnbuckles (Bluesea)
• Keel stepped aluminum mast & Aluminum boom
• Double spreaders
• Running backstays
• Internal halyards/outhauls
• All standing rigging oversized compressed strand 2010

Winches

• (1)  Harken 900 Unipower Electric ST Mainsheet/Haylard winch
• (2 ) Anderson 52 Primary Lewmar ST electric winches
• (2) Lewmar 30 ST winches on cockpit coaming
• (2) Lewmar 40 ST winches on mast
• (2) Lewmar 30 winches on mast

Mechanical

Yanmar 4JH-TE 75hp w/ 3153 Hrs.

• 1 1/4” stainless steel shaft
• Dripless Shaft Seals
• Feathering MaxProp 3 Blade
• Morse controls at helm
• (3) Racor fuel filters
• Water lift muffler
• Par electric bilge pump with auto switch
• Rule 3700 high capacity bilge pump
• Manual bilge pump in cockpit
• Bilge high water alarm
• Foam and lead engine room sound insulation

Safety /Miscellaneous

• Plastimo 8 man, offshore life raft (2023)
• Secondary anchor, Fortress Danforth style. No rode.
• Bosun’s chair
• Fenders
• Fender board
• Flares expired
• Fire extinguishers
• EPIRB
• Custom Teak Helm Seat
• Keeble Aluminum Framed Winter Cover
• Spare new H/C water pump.
• Spare Hitachi alternator for Yanmar engine
• Spare Toilet pump
• Spare propellor for Vetus bow thruster.
