Construction:

• Design following European Directive requirements and according to EC certification
• Monolithic hull design in polyester
• Monolithic structural inner molding bonded to the hull
• Injection molded deck in glass fiber/balsa sandwich, covered with "diamond-point" non-slip coating
• Hull-deck join screwed, bonded, and trimmed with 1 bulwark
• Cast iron keel fixed with bolts and stainless steel backing plates
• Rudder hung with glass compound stock
• White-colored hull - Grey metal hull graphics

Rigging:

• In mast furling Mainsail
• Standard mast 9/10 anodized aluminum installed on the deck, 2 aft-swept spreaders
• Anodized aluminum boom
• Discontinuous stainless steel standing rigging
• 2 Backstays with bottlescrews
• Rigid boom vang with tackle
• Spinnaker halyard
• Genoa furling system with a drum on the deck
• 2 Blocks Stand-Up on mainsheet arch
• 2 genoa tracks with piston-adjusted traveler cars
• 2 Genoa sheet return blocks
• Rigging run back to the cockpit (except boom topping lift)
• Complete running rigging: Main halyard, genoa halyard with a clutch on mast and cleat, Boom topping lift with cleat on mast, Mainsheet, 2 Genoa sheets two rapid reefing lines, one manual reef
• 7 Jammers
• 2 halyard bags

Sails:

• Furling mainsail w/battens w/ UV protective cover
• Furling Genoa with UV protective strip

Winches:

• 2 Self-tailing Genoa sheet winches
• 1 Self-tailing Electric winch on the port cabin top
• 1 Self-tailing cabin top starboard manual winch
• 1 Aluminium Speed Grip winch handle
• 1 Winch handle box

Mooring Lines - Mooring:

• Self-bailing chain locker - Clench bolt - Hatch cover
• Single roller stainless steel bow fitting with offset roller
• 6 Aluminium mooring cleats - Stainless steel deck line protection

Safety On Deck:

• 1 Open stainless steel forward pulpit
• 2 Stainless steel aft pushpits
• 1 Outboard engine bracket
• Ring for flag welded on balcony
• Double guardrail and stainless steel stanchions - Opening to port and to starboard in guardrail

Cockpit:

• Self-draining cockpit
• 2 Cockpit lockers
• 2 Lockers in cockpit sole beneath helm's feet
• Liferaft locker under the helm seat, in cockpit bottom (2’7’’ x 1’4’’ x 1’11’’)
• 1 Gas locker for bottle(s) under the port helm seat
• Natural solid wood slatted cockpit benches
• 2 Steering wheel consoles: Stainless steel steering wheels - leather covered - Steering gear at the helm station - metal cable transmission system - Stainless steel handrail - navigation instrument support (optional instruments) - Glass holder
• 1 Deck hole for access to tiller system + Power supply access hatch
• 1 Emergency Tiller
• 2 Steering compass on binnacle
• Portside engine control and control panel
• Polyester cockpit table - 2 flaps - oddments locker - 2 Large storage space - 2 Stainless steel handrails - 12 V socket - lamp with shade
• 1 Cold water cockpit shower hose
• 1 Mainsail arch (lit, Compound, Built-in lighting)
• 2 Hinged PMMA companionway doors - Sliding hatch made of PMMA

Swim Deck/Stern Deck:

• Fully opening transom, convertible to bathing platform (9’4’’ x 2’6’’)
• Electrically controlled opening
• Natural solid wood decking on sun deck
• 1 Stainless steel swim/boarding ladder - solid wood steps - folding

Electronics:

• Zeus chartplotter - 12 Ext.
• Simrad wifi module
• Cartography B & G US
• B & G Autopilot
• Nav tri-function - B & G
• Wind machine - B & G
• VHF + Wireless + AIS US
• Radar - B & G

Interior:

• 3 cabin/ 1 head version
• Woodwork - Alpi Mahogany
• Parquet-type laminated floors
• Fabric hull linings in saloon and cabins (White)
• Fabric upholstery - Ultaleather Parchment
• Air conditioning
• Marine mattresses in the cabins

Companionway:

• Headroom: 6’4’’
• Wooden saloon companionway with molded wood suspended steps with non-slip surface
• 2 Stainless steel handrails

Saloon:

• Headroom: 6’5’’
• U-shaped saloon bench - double-density foam
• Saloon table in 1 piece - Varnished wood top with inlay - Aluminium legs
• Mirror on the starboard bulkhead
• Cupboards - Shelves and stowage along the hull - Storage under bench seats
• Shelves with stainless steel fiddles
• 2 Coachroof panoramic windows with curtains
• 2 Hull portholes with curtain
• 2 Opening portholes on coaming in side windows
• 1 Opening deck hatch with blind / Mosquito net

Chart Table:

• Sliding can be configured with the armchairs - Placed against the forward bulkhead, against the galley or between the 2 mobile seats
• Table with flap-molded wood fiddle
• Switch panel on bulkhead for access to electrical functions
• 1 Reading light

Galley:

• Headroom: 6’2’’
• L-shaped kitchen
• Compact grey laminated worktop
• 1 Stainless steel sink 2 rectangular basins - 1 Mixer tap cold water / hot water, under pressure
• 1 Gas cooker 2 burners - Stainless steel oven on mountings - Stainless steel protection handrail
• Microwave
• 1 22 US Gal, top opening freezer
• 1 12 V 34 US Gal, front opening refrigerator
• Fitted lockers and closed shelving - Bin
• 1 Base cabinet: 1 Drawer - 2 Shelves
• 1 Opening portlight with curtains in side windows in the coaming
• Storage space along the hull

Forward CabinL

• Headroom: 6’3’’
• Central double bed (6’7’’ x 6’2’’ x 1’8’’)
• Hanger closets - Valet tray - Cubby hole locker - Base cabinet - Stowage under platform
• 1 Dressing table
• 3 flush deck hatches with blinds / Mosquito net
• 2 Hull portholes with curtain

Adt Cabin - Starboard:

• Headroom:6’2’’
• 1 Double bed (6’7’’ x 5’3’’ x 4’2’’)
• Access door to starboard aft washroom
• Cupboards - Hanging locker - Closed shelving
• Bed access sideboard
• 1 Hull porthole with curtain
• 1 Cockpit window with curtains
• 1 Porthole opening onto the cockpit with curtain
• 1 flush deck hatch with blind / Mosquito net

Aft cabin - Port:

• Headroom: 6’2’’
• Double bed - Port cabin (6’7’’ x 4’8’’ x 3’7’’)
• 1 Bed access sideboard
• Cupboard - Hanging locker - Closed shelving
• 1 Hull porthole with curtain
• 1 Cockpit porthole with curtain
• 1 flush deck hatch with blind / Mosquito net
• 1 Cockpit window with curtains

Head (Starboard Aft):

• Headroom:6’1’’
• Access through the saloon and the starboard aft cabin
• Separate shower - 1 Mixer tap hot water / Cold water
• 1 Manual marine toilet
• 1 Rigid holding tank 80L / 21 US Gal
• Basin - 1 Mixer tap hot water / Cold water
• Washroom cabinet
• 2 Mirrors
• Toilet accessories
• Cupboard
• 1 Opening portlight with curtains in side windows in the coaming

Engine:

• Engine Yanmar Diesel 40 hp / 40 HP Sail Drive
• Engine control - Control panel in cockpit
• Engine compartment: Soundproofing foam - Ventilation: 1 air intake and 1 pressured air outlet • 1 Alternator 12 V / 125 Ah
• 1 Rotomoulded diesel tank - 53 US Gal (under port aft berth) - Electronic gauge - Low-level alarm - 1 Deck filler
• Filters: Sea water - Diesel - Decanter
• 3-blade propeller
• 1 Engine access through companionway (opening with two gas struts) - 2 Engine access through aft cabins

Electricity:

• 12 V circuit
• AGM batteries
• 1 Power distributor
• 12 V Electrical panel (Fuses - Voltmeter - Water gauge - Fuel gauge - Battery warning - Fuel warning - Water warning)
• 1 12 V Sockets
• Lighting: Overhead lights - Reading lights
• Navigation lights: 1 Forward and aft navigation lights - 1 Engine navigation light / Spreader light forward of mast - 1 Anchor light on masthead
• Full 220 V system (Interior sockets 220 V, 40 Amperes battery charger, Shore power socket)

Plumbing:

• 1 rotomoulded freshwater tank - 87 US Gal
• Additional rotomoulded freshwater tank - 53 US Gal
• 2 Deck fillers
• Pressurized electric water pump - Expansion tank - Inline filter
• Electric water heater - 1 US Gal (engine run)
• 1 Rigid holding tank - 21 US Gal (Starboard aft head compartment)
• Delayed shower draining and electric shower drain pumps
• 1 Electric bilge pump - 1 Manual bilge pump
• 1 Electric ice box drain pump

Propane:

• 1 Gas bottle box in the cockpit (Diameter 1’1’’ x 1’9’’)
• Regulator and safety tap

Cruising Pack:

• Radar B&G
• Flag halyards - 2
• Inner forestay chainplate
• Extra bow roller
• Rubrail
• Bowthruster
• Extra water tank (as noted above)
• Foot pump fresh/seawater
• Inverter 12/110 V
• Folding prop
• Simrad stereo satellite receiver

Safety Package:

• Mantus anchor
• 75" chain and anchor rode

Additional Options:

• Electric flush fresh water toilet
• Flat-screen TV & TV antenna
• Air conditioning - Cruisair - 2 units
• Cockpit cushions
• Bow thruster
• Dodger, Bimini, and connector - Slate grey
• Wheel covers - slate grey
• Salon double berth w/pivoting table
• V berth backrests
• Wood cockpit floor
• Movable stool in the forward cabin
