2023 Bilgin 137'
41.86 m2023 Bilgin 137'
KASIF with her modern design, technology, large GT at 381 and extended range of up to 5,000nm is a very rare offering to find for sale with immediate delivery.
Description
KASIF represents a highly capable transoceanic full displacement steel hull yacht, designed for comfort at sea with lavish appointments. Designed by two award winning designers with exterior by Unique Yacht Design and interior by HOT LAB. Large volume of 381 GT and 8’ draft assure she is capable of cruising anywhere on the globe. Fitted with at rest stabilizer by ABT Trac and reliable CAT power. Rare to find like new yacht ready for immediate delivery with under 500 operational hours.
LOA137'
LOA Inch4''
LOA41.86''
Beam26'
Beam Inch5''
Draft Max Feet8'
Draft Max Inch2''
Draft Min Feet7'
Draft Min Inch8''
Fuel Tank (Gallons)11116.89
Fuel Tank (Liters)42082
Fresh Water (Gallons)2695.08
Fresh Water (Liters)10202
Holding Tank (Gallons)542.08
Holding Tank (Liters)2052
TypePower
ConditionUsed
Specifications
KASIF
9993145
137'4" (41.86 Meters)
Power-Used
2023
26'5"
127'7"
8'2"
7'8"
5
10
2
1
Yes
Yes
6
4
Yes
6
1
14 Knots
10 Knots
3660
Diesel
Aluminum
Steel
Awlgrip
Displacement
Yes
Zero Speed
ABT Trac
11116.89 Gallons (42082 Liters)
2695.08 Gallons (10202 Liters)
542.08 Gallons (2052 Liters)
381
360
RINA
Bilgin
Hot Lab
Bilgin
Description
Engines
Engine 1
- Engine Make: Caterpillar
- ModelEngine Model: C18
- Engine TypeEngine Type: Inboard
- Power HPPower HP: 670.51
- Power KWPower KW: 500.00
- Feul TypeFeul Type: Diesel
- HoursHours: 403.00
- Engine LocationEngine Location: Port
- Hours DateHours Date: 06-13-2024
Engine 2
- Engine Make: Caterpillar
- ModelEngine Model: C18
- Engine TypeEngine Type: Inboard
- Power HPPower HP: 670.51
- Power KWPower KW: 500.00
- Feul TypeFeul Type: Diesel
- HoursHours: 401.00
- Engine LocationEngine Location: Starboard
- Hours DateHours Date: 06-13-2024
Generators
Generator 1
- Generator Make: Caterpillar
- Generator Model: C4.4
- Generator KW: 75.00
- Generator Hours: 668.00
- Generator Date Hours Recorded: 06/13/2024
Generator 2
- Generator Make: Caterpillar
- Generator Model: C4.4
- Generator KW: 75.00
- Generator Hours: 681.00
- Generator Date Hours Recorded: 06/13/2024
Multimedia
Full Details
Detailed Specification
MAIN CHARACTERISTICS
Name: KASIF
Type: Displacement
Builder: Bilgin Yachts
Year: 2023
Hull No: NB79
LOA (M/FT): 41.86M (137’04”)
LWL (M/FT): 38.90M (127’07”)
Length COR: 38.90M (127’07”)
Beam Overall (M/FT): 8.07M (26’05”)
Beam moulded (M/FT): 8.40M (27’06”)
Draft (Half Load) (M/FT): 2.36M (7’ 07”)
Draft (Full Load) (M/FT): 2.50M (8’ 02”)
Gross Tonnage: 381
Displacement (Fully Loaded): 360
Displacement (Half Loaded): 331
Displacement (Light Ship): 293
Hull Material: Steel
Hull Configuration: Full Displacement
Superstructure: Aluminium
Decks: Teak
Flag: Cayman Islands
Classification: Rina
Vessel Registration: Private
Naval Architect: Unique Yacht Design
Exterior Designer: Unique Yacht Design & Naval Architecture
Interior Designer: Hot Lab
Main Engines: Cat C18
Speeds: 14 kn Max
10 kn Cruising
8 kn Economical
Range: 5,000 nm @ 8 kn
Guest Accommodation: 10 guests in 5 staterooms
Crew Accommodation: 6
COMMENTS AND NOTEWORTHY FEATURES AT A GLANCE
KASIF is being offered for sale in better than new condition, delivered in 2023 with under 500 hours on the main engines, assuring the next owner will benefit from the first year of shakedown use now taken care of. Her modern explorer yacht design was inked by the very popular and award-winning Unique Yacht Design, who is also responsible for the naval architecture and performance of the full displacement steel hull. This is the 8th hull Unique Yacht Design has done for Bilgin. KASIF’s full displacement steel hull assures comfort at sea, long cruising range and transoceanic capabilities.
The Owners are repeat new build customers with Bilgin and have a rich background in both architecture design and commercial ship operations. They hired interior designer Hot Lab and collaborated together, considering every cosmetic and technical detail possible. The interior design features an oversized main deck master stateroom, below deck is the full beam VIP stateroom offering extra comfort at sea, two double staterooms and one twin stateroom. The extra-long swim platform and full-service beach club, give amazing access to everything happening on the water. A large exterior aft bridge deck and bow seating in front of the bridge on the same level offer vast spaces for relaxing and dining. Sundeck features additional seating and bar for entertaining. The exterior spaces are extraordinary for a 42 meter design.
KASIF with her moder design, technology, large GT at 381 and extended range of up to 5,000nm is a very rare offering to find for sale with immediate delivery.
Highly successful Unique Design and Hot Lab design collaborations
Up to 5,000 nm range
RINA class, unrestricted ocean cruising range, Yacht Reg Code compliance
Full displacement steel hull affording comfort at sea and long range with only 8’ draft
Reliable CAT main engines and generators
ABT Trac at rest stabilisers
CLASSIFICATION
Flag: Cayman Islands
Port of Registry: George Town
IACS Society: Rina
Additional Class Information: C ✠ HULL • MACH; Y, Unrestricted, Reg Yacht Code Compliance
IMO Number: 9993145
MMSI Number: 319276200
Official Registration: 753236
Home Port: Bodrum
SQUARE METERS
TOTAL EXTERIOR DECKS: 276.50M² (2,976FT²)
TOTAL INTERIOR: 240.50M² (2,588FT²)
Sun Deck: 38.50M² (414FT²)
Bridge Deck Total (Interior): 34.00M² (366FT²)
Upper Saloon: 30.00M² (323FT²)
Lobby: 4.00M² (43FT²)
Main Deck Total (Interior): 83.50M² (899FT²)
Main Saloon: 27.00M² (290FT²)
Dining Room: 15.00M² (161FT²)
Owner’s Stateroom: 36.00M² (387FT²)
Lobby: 5.50M² (59FT²)
Lower Deck Total (Guest): 84.50M² (910FT²)
VIP Stateroom: 24.00M² (258FT²)
Double Stateroom I: 13.00M² (140FT²)
Double Stateroom II: 12.00M² (129FT²)
Twin Stateroom: 11.00M² (118FT²)
Lobby: 4.50M² (48FT²)
Beach Club: 20.00M² (215FT²)
Crew Quarters (With Captain): 37.00M² (398FT²)
DECKHEAD HEIGHTS
Main Deck Exterior: 2.20M (7’ 02”)
Main Salon: 2.20M (7’ 02”)
Bridge Deck Interior: 2.10M (6’ 09”)
Bridge Deck Exterior: 2.15M (7’ 01”)
Lower Deck Interior: 2.10M (6’ 09”)
ACCOMMODATIONS
OVERVIEW:
KASIF embodies the true spirit of an explorer. Exceptionally capable world-cruising yacht, she offers a unique blend of performance and total comfort. The hull, derived from the acclaimed 80-meter series, delivers remarkable efficiency, consuming minimal fuel while achieving impressive speeds.
ACCOMMODATION:
2 x Salons, 1 x Master stateroom, 1 x VIP stateroom, 2 x Double guest staterooms, 1 x Twin guest staterooms.
LOWER DECK:
Beach Club
The VIP stateroom offers an expansive and lavishly appointed space for guests with its elegant design.
The twin stateroom offers an inviting décor and functional layout.
The double guest staterooms are spacious and present a fresh design with tasteful décor.
MAIN DECK:
The master stateroom boasts a spacious and exquisitely designed interior with its own dedicated seating area and a luxurious en-suite bathroom.
BRIDGE DECK:
Moving to the upper deck, a more masculine palette dominates, setting the stage for the living and dining areas as well as the owner's office with a sophisticated atmosphere.
CREW ACCOMMODATION:
1 x Captain’s cabin, 2 x crew cabins for 2, 1 x crew cabin for 1.
CONSTRUCTION
Hull Material: Steel
Bulb: Yes
Superstructure Material: Aluminium
Decks Material: Teak
Paint: Awlgrip
Motor Hull Type: Full Displacement
Number of Decks: 4
CAPACITIES
Gross Tonnage: 381
Net Tonnage: 114
Displacement Tons: 360
Fuel Capacity: 42,082 Litres (11,116 Gallons)
Day Tank: 5,920 Litres (1,564 Gallons)
Storage Tanks: 36,162 Litres (9,553 Gallons)
Fresh Water Capacity: 10,202 Litres (2,695 Gallons)
Grey Water: 4,920 Litres (1,300 Gallons)
Black Water: 2,052 Litres (542 Gallons)
Bilge Water Tank: 444 Litres (117 Gallons)
Lube Oil: 397 Litres (105 Gallons)
Waste Oil: 397 Litres (105 Gallons)
Speed kn Consumption L/h Range nm RPM
Maximum: 14 283 2,000 2,140
Cruising: 10 115 3,660 1,440
Economical: 8 65 5,000 1,140
Consumption at Anchor: 15 lt
MAIN MACHINERY
Main Engines: 2 x C18 500 kW @2,100 RPM imotier II Marine Diesel Engine
Engine Hours: Port: 403
Starboard: 401
Propulsion Type: Conventional propulsion with two engines
Engine Controls: Cat
Engines Exhaust System: Custom
Gear Boxes: ZF
Shafting: 2 x Ø115mm, 1.4462 F51 Steel, water lubricated
Propellers: 2 x 4 Blade, Ø1,400mm
Engine Ventilation: Gianneschi
GENERATORS & ELECTRICITY
Generators: 2 x CAT C4.4 2x75 kW, Marine Diesel Generator
Generator Hours: Port: 668
Starboard: 681
Shore Power Converter: Seapower
Batteries: Victron
Battery Chargers: Victron
AUXILIARY MACHINERY
Steering System: Data Hydraulic
Steering Gear: Data Hydraulic
Emergency Steering: Data Hydraulic
Bow Thruster: Side Power SAC1100/513
Stabilisers: 2 x ABT-TRAC
Under Water Lights: 4C Innovation
Helm/Wing Station Controls: CAT
Fuel & Oil System
Fuel Oil Separator: GEA
Fuel Transfer Pump: Gianneschi
Fuel Filling Pump: Gianneschi
Oily Bilge Water Separator: RWO
Dirty Oil Pump: Gianneschi
Lubrication Oil Pump: Gianneschi
Firefighting & Bilge System
Firefighting & Bilge Pump: Gianneschi
Fresh Water System
Fresh Water Makers: Idromar 2 x 9,000 lt / day
Fresh Water Treatment: Idromar
Fresh Water Pressure: Gianneschi
Hot & Cold Circulation Pump: Gianneschi
Hot Water Boilers: Diko 2 x 150 lt /day
Sea Water Pumps: Gianneschi
Black & Grey Water System
Black & Grey Water Treatment: Tecnicomar 3,200 lt / day
WC's (toilets/bidets): Jets Vacuum System
Sanitary Vacuum System: Jets Vacuum System
Black & Grey Water Pumps: Gianneschi
AC & Ventilation System
Air Conditioning: Webasto 252000 BTU/h Chiller Capacity
Air Compressor: Atlas Copco
Engine Room Ventilation: Gianneschi
Hydraulic System
Hydraulic Power Packs: Trac
Antifouling System
Type: Cathelco ICCP and MGPS
Safety & Security
Fan and Fire Dampers: Gianneschi
NAVIGATION & COMMUNICATION SYSTEMS
NAVIGATION SYSTEMS
Navigation Bridge: Navigation Equipment is fitted in accordance with regulations A3 unrestricted navigation
Monitors: Simrad MO24
X-Band Radar: Simrad R5024
Halo Radar: Simrad Halo 6
Chart Plotter: Simrad
Gyrocompass: Simrad GC80
Auto Pilot: Simrad AP70
Rudder Angle Indicator System: Simrad I3007
Echo Sounder: Simrad S3009
Speed Log: Simrad SAL R1A
GPS Compass: Simrad HS80A
GPS: Simrad GS25
AIS: Simrad
Navtex: Sailor 6391
Wind Instruments: Simrad
Horn: Kahlenberg
Search Lights: Sanshin
Bridge Navigation Watch Alarm: Veinland
DECK MACHINERY & EQUIPMENT
Anchor Windlass System: Data Hydraulic
Cranes: Opacmare
Mooring Capstans: Data Hydraulic
Passerelle: Opacmare
Transformer: Opacmare
Paint Exterior: Awlgrip
Paint Interior: International
Paint Underwater: International
ENTERTAINMENT
Entertainment System: Savant / Lutron
GALLEY & LAUNDRY EQUIPMENT
MAIN GALLEY EQUIPMENT
Cooking Equipment: Miele
Refrigeration/Freezer: Electrolux
Dishwasher: Miele
CREW GALLEY / MESS EQUIPMENT / COOKING EQUIPMENT
Microwave: Miele
Refrigeration/Freezer: Electrolux
Dishwasher: Miele
Main Laundry Equipment: Miele
EXCLUSIONS
Exclusions include all of Owner’s personal effects. A detailed list of inventory and exclusions will be provided pursuant to a purchase agreement.
DISCLAIMER
NOT FOR SALE OR CHARTER TO U.S. RESIDENTS WHILE IN U.S. WATERS
All speeds, measurements, capacities, consumptions, etc. may be approximate or estimated. Specifications provided for information only. Data was obtained from sources believed to be reliable and is not guaranteed by owner or brokers. Buyer assumes the responsibility to ascertain the correctness of all data contained herein and otherwise provided and must instruct his agent and surveyors to confirm all details for accuracy prior to purchase. Subject to prior sale price and inventory change or withdrawal from market without notice.
