FEATURES

• New Twin Cummins Engines QSB6.7 - 300 hp (in 2021)
• Newly Matched w/ ZF Gears to Optimize Performance w/ Hull Design (2021)
• Average Fuel Consumption 4 GPH at 8 kn - 1250-1400 rpm
• Ocean Cruising Range of 4,000 NM
• Wide Beam Hull, Stabilizing Chocks and Bulbous Bow
• New x3 Garmin Multifunction & Navigation Displays in the Pilothouse & Flybridge (2021)
• New x2 Radar domes (2021)
• Newly Added Cummins Displays Giving Complete Array of Engine Data (2021)
• New Remote - Yacht Controller - (Bow & Stern Thrusters & Engines Control) (2021)
• New Maretron Tank Management System (2021)
• Exceptionally Large Engine Room - (10' 8" L x full beam x 6' headroom)
• Lazarette, aft of engine room - (13' 5" L x full beam x 6' headroom) a very special room that houses a workbench, tools, spare parts, a lot of open storage
• New x7 Cameras added to the Vessel's Exterior and Engine Room (2021)
• New Nick Jackson Davit 1,500 lb (2021)
• Village Marine Watermaker
• New Refrigeration in the Galley x4 (2021)
• New Upgrade to the Galley Venting (2021)
• Hard Top Protection for the Flybridge
• Newly added Stainless Steel Safety Railing to the Flybridge (2021)
• Boat House Kept

HULL & SUPERSTRUCTURE

• This yacht is extremely stable and comfortable, providing an exceptional travel experience
• A modified displacement hull complimented by the wide shape, minimizes sideways swing
• This displacement hull comes to a wave piercer at the bow with the addition of the bulbous bow, minimizing the impact of sea conditions while increasing the waterline length and reduction in drag
• Reinforced chocks added to the hull, further reduce the rocking motion of side-to-side
• A thick, properly built, tough hull incorporates several layers of fiberglass, Kevlar & coring with Divinycell in the hull sides
• Robust stringers were designed into the construction, adding reinforcing strength to take on big seas
• 9,600 lb of lead weight added to the full-length ballast keel, lowering the center of gravity
• Sharp bow but widens quickly to maximize interior space
• High bow reduces splash-over and soaking of the fore deck
• The quality of the finish is superior because isophthalic polyester resin was used
• Full wide walk-around deck - inspiring free movement
• Deck is cored fiberglass with thick teak strip overlay
• Portuguese bridge separates the pilothouse from the fore deck - a lot of storage added into this wall
• 316 S/Steel oval hand rails surround the deck
• 4-1/2 ft added to hull as swim platform - includes x3 tightly sealed Freeman storage hatches & 2" S/S moveable staples for safety

MAIN LEVEL LIVING SPACE

• A wide open salon with large windows contribute to visually blending the interior with exterior
• The spaces inside are designed to accommodate a variety of uses
• Exotic woods have gone into every detail.
• 3/4" Brazilian Jatoba hardwood w/maple inlay main level sole
• Cherry wood cabinets adding to the the rich colors
• Wrap-around settee, button upholstered with a custom inlay dining table
• Newly added x2 comfortable armchairs creating an essential spot to sit and enjoy a good book or catch up with friends
• Large TV cabinet that raises up with a touch of a button(New TV 2021)
• Large well-equipped galley to port includes Corian counter & 2 bar stools
• Wet bar and lighted cabinets to starboard
• All lighting LED & USB charging stations
• Flooring has added sound proofing

GALLEY

• Large U-shaped style and to port
• Upper and lower cherry wood cabinets w/self closing maple drawers
• Well-lit - LED overhead lighting
• Stove/Oven - American Range commercial grade 5-burner propane w/full size convection oven
• Refrigeration system - x4 S/S Isotherm pullout style (new 2021)
• Additional 3.5 cu. ft freezer below in lazarette
• Venting upgrade - Arda venting hood to vent outside
• Microwave - yes
• Double S/S sink
• Dishwasher - Fisher Paykel
• Corian black shale counter tops
• Propane storage in cockpit

ACCOMMODATION-LOWER LEVEL

Custom spiral staircase, made from African Padauk and accented w/dark red Brazilian hardwood, leads you down to the staterooms.

• Master suite-Located mid ship and designed for quiet and peaceful comfort
• The centrally located queen bed allows easy movement throughout the master chamber
• The compliment of beautiful wood finishing extends to these suites
• Dedicated space when getting ready for the day - off to the side is a nicely built in dresser & mirror
• Full size heated bathroom, walk-in shower- Vacuflush head (heated flooring and towel bars)
• Full size closets and multiple drawers for storage
• Matching door opens to full size washer/dryer
• Opening screened portlights allowing fresh air flow

• Fwd Stateroom- nice separation from the master suite
• Queen sized raised bed -
• Easy full walk around
• Hang up lockers & multiple storage drawers
• Ensuite includes heated flooring and heated towel racks
• Full standup shower
• Vacuflush head
• Opening screened deck hatch and portlights

PILOTHOUSE

• MULTIFUNCTION DISPLAY & NAVIGATION
• Hydraulic steering system from pilothouse and flybridge
• 2 station EVC throttle & shift controls
• x2 Garmin GPSmap 8616 (New)
• x2 Garmin GPS EUHD72cv
• Garmin GMR Fantom 24
• x2 Garmin 24"radar domes (New)
• Garmin Reactor 40 autopilot
• Garmin GHC 20 autopilot
• MaXimo Yacht Controller-Dual Band-Remote
• VHF Radios: Std Horizon Quest-X, Navman 7100, SH Ram+mic
• Compass: Ritchie powerdamp 5" & 3.5" upper helm
• Garmin GTS transducers
• Raymarine wind/weather MN-100
• Vetus Bow & Stern thruster controller
• Garmin AIS 800
• Garmin GC 200 IP Camera (New)
• Tankwatch system (New)
• Thrane Iridium satellite system (New)
• Fusion sounds system (New)
• Window defoggers (New)
• Northern Lights Genset control
• Swivel pedestal seating for pilot
• Bench seating w/table for others
• Starboard and port sliding exit doors. Multiple position locking
• Main access to flybridge
• Spiral staircase leading to lower level

ENGINES & ENGINE ROOM

• Engines - New Cummins engines, gears and shafts (2021)
• x2 Cummins QSB6.7 - 300 hp (2021) - 582 & 587 hrs
• ZF 85 series reverse reduction marine transmissions
• New Stainless steel 2" shafts w/ PYI dripless shaft seals
• 3 blade 28x27 (RH & LH) bronze propellers w/ twin line cutters
• Large individual spade rudders
• x2 Spare props
• Natural & evacuation thermostatically controlled blowers - Expanded fresh air venting
• Racor, Dual filter 100 FG
• Algae-X Fuel polishing
• Type A2 Fuel supply lines
• SM1 was designed for a wide open & standup engine room, allowing great all-around access to the engines and equipment.
• Amazingly clean, bright and organized- (10' 8" L x full beam x 6' headroom)
• A separate workshop was built aft of the engine room for your tools, gear and repairs
• Engine room is sealed behind watertight bulkhead doors. Infrared cameras installed to keep watch while underway!
• Access Through Master suite or the aft deck
• Lazarrete- behind engine room - (13' 5" L x full beam x 6' headroom)
• This space includes x2 tanks, tools & work bench, parts, freezer, watermaker and a lot of free storage space
• Accessed through engine room or through an opening hatch in the cockpit

ELECTRICAL

Distribution panel

Blue Seas panel located both at the main helm & engine room

AC

50 Amp shower power

75 ft power cord with electric retrieval

Victron Energy 24V/3000 Watt/ 70amp inverter charger

Mass Combi 24V/2500 Watt/ 70 amp inverter charger

DC

24 VDC & 12 VDC systems

Battery bank setup:

x8 - 6V AGM house bank

x4 - 12V AGM start - x2 per engine

x1 - 12V AGM Genset start

x8 - 12V (24V system for thrusters)

Generator

Northern Lights 12 KW

Additional Power

400 Watt Solar

EFOY automatic backup charging

x2 - 140 amp alternators

DECK EQUIPMENT

Windlass

• Lofran Tigres horizontal w/ capstan and chain gypsy
• Foot switches, hand held unit and helm controls to raise and lower
• Nordhavn 120 lb Stainless steel CQR
• 400' 3/8" New chain
• Bow Pulpit/Rail 1 1/4" Stainless steel
• Hawes pipes & bollard Stainless steel
• Spare Anchor included
• Wash down station
• Chain counter

Tender and Davit-Upper Deck

• Nick Jackson 1500 davit (New upgrade)
• Caribe 11' inflatable center console tender
• Garmin chartplotter (New)
• Yamaha 25 hp outboard
• Full tender canvas cover

Deck gear

• Multiple cameras installed surrounding the vessel
• Well lit deck with multiple exterior lights
• HD Cleats, Stanchions and Safety rails
• Stainless steel cleats
• 4" wide, custom handcrafted, soft leather fender hooks
• 1 1/4" S/S stanchions and oval safety rails surround the vessel - beefed up on the flybridge
• 1" & 1 1/4" S/S grab rails
• Water toy storage ample
• Extra interior venting through various hatches and portlights
• 3 Freeman watertight hatches in the swim grid - a lot of extra storage
• Propane storage locker in cockpit

ADDITIONAL EQUIPMENT

• Village Marine Water maker
• Hoover Hush central vac
• Hurricane heating throughout the vessel
• Ready to install air conditioning unit (never used)
