SPECIFICATIONS

Dimensions

• Length Overall w/o engines: 30'6" (9.30 m)
• Beam: 10'7" (3.23 m)
• Bridge Clearance: 8’7” (2.62 m)
• Draft: 21" (0.53 m)
• Cockpit Depth: 27” (0.69 m)
• Displacement: 6,950 lbs (3,152 kg) without engines
• Hull Material: Fiberglass
• Hull color: Celestial Blue
• Deck Material: Nonskid fiberglass
• Transom Dearise: 19.5 degrees (SeaV progression)

Engines

• Engines: Yamaha
• Total Power: Twin F300 HP (total 600HP)
• Maximum HP: 500 (522 kW)
• Fuel: Gasoline

Tanks

• Fuel Tank Total Volume: 290 gal (1,098 L)
• Water Tank Total Volume: 32 gal (121.1 L)
• Holding Tank Total Volume: 7.5 gal (28 L)

Accommodations

• Guest Heads: 1

INTERIOR ACCOMMODATIONS AND LAYOUT

Head, Interior Styling & Features:

• Composite cherry & holly sole
• Fold-down seat
• Helm access door with light
• Lockable console with lighting
• Marine head with electric flush, 7.5-gallon (28 l) holding tank, macerator, overboard discharge, and deck pump-out
• Shower, sink, and bulk storage drawers

NAVIGATION AREA AND ELECTRONICS

Electronics

• Deluxe stereo system with waterproof touch screen display AM/FM tuner, Wi-Fi & Bluetooth® connectivity
• Flush mounted twin Garmin 12” Screens (normally as option)
• Helm subwoofer and speakers with LED lights (bow (2), T-top (2), and cockpit (2))
• Transducer mounting flats

Helm/Console

• Accessory outlets: 12V and 5V USB

·        Battery select switches (one per engine)

• Compass
• Companion grab rails

·        Deluxe stereo (see electronics)

• Drink holders - stainless steel (3)
• Molded console footrest helm & companion
• Port & starboard bow seating w/forward facing
• foldaway bolstered backrest (2)
• Seating: Molded forward console seat with cushion
• Steering: Helm Master® EX with Integrated Digital Electric Steering

·        Steering wheel - 316 grade stainless steel w/knob

• Trim tabs indicators
• T-top - fiberglass w/painted aluminum frame, radio box,
• storage net, tri-colored (red, blue, white) LED recessed
• lights (4), fore/aft spreader lights, rod holders (4), radar flat
• & outrigger plates
• Ventilation
• Window - tinted frameless acrylic
• Windshield: Laminated glass integrated with T-top, wiper, and washer

Cockpit

• Blue LED cockpit lights
• Bolsters (cockpit and forward)
• Drink holders – stainless steel (7)
• Freshwater shower (recessed)
• Foldaway aft bench seat with cushion
• Hydraulic trim tabs indicators and retractor
• Insulated fish/ice boxes:
• 150-qt. (port & starboard), ob drain (2)
• 304-qt. aft w/divider, lighted, ob drain
• Self-bailing cockpit with drains
• Side door with boarding ladder
• Step - starboard
• Rod
• holders - bow (2), cockpit (6)
• storage - lockable horizontal (6)
• storage racks - horizontal (3)

Deluxe Lean Bar

• Drink holders - stainless steel (2)
• Footrests - fold down (2)
• Knife & plier holders
• Livewell - 47-gallon (177.9 l) insulated raw water livewell w/light, full column distribution inlet & ob drain (1100 GPH pump) (4164 LPH)
• Rigging station - freshwater sink w/pullout faucet & insulated bait box
• Rod holders (4)
• Seating - lean bar mounted Command Elite helm chairs (2)
• horizontally adjustable w/deluxe cushioning & flip-up
• bolsters
• Storage - lockable storage drawers

CONSTRUCTION, HULL & DECK

Hull

• 100% hand-laid SeaV² hull
• Composite stringer system and transom (water impervious)
• Stainless steel through-hull fittings
• Hull color: Celestial Blue

Deck, Forward (Bow) and Transom

• Anchor windlass with rode, line, and remote switches at helm
• Integrated outboard mounting system with swim platform & ladder
• Flush-mount cleats (pull up)
• High-density PVC rub rail with stainless steel insert
• Hardware - 316 grade stainless steel through-bolted
• Stern eyes - 316 grade stainless steel
• Transom door - fiberglass

Ground Tackle

• Anchor windlass
• Storage - forward anchor locker w/rode storage

SHIP SYSTEMS

Engine and Mechanical

• Engine flush system with hose attachment aft (one per engine)
• Factory engine pre-rigging
• Hydraulic trim tabs and retractor
• Twin Yamaha F300

Plumbing & Tankage

• Freshwater washdown (forward & aft) with hose
• Pressurized raw water washdown (forward & aft) with hose

Electrical System

• 12V system

·        Battery charger (1)

• Batteries (3) with battery select switches at console
• Dockside power with galvanic isolator
• International lighting
• LED lighting throughout

SAFETY EQUIPMENT

• 2x automatic bilge pumps (2600 GPH total) (9842 LPH)
• Basic flotation
• Bow grab rail and cockpit toe rails
• Composite stringer system & transom - water impervious

·        Fire extinguisher holder

• Non-skid fiberglass liner

·        Self-bailing cockpit w/cockpit drains (4)

EXTRAS, OPTIONS

• Bow thruster
• Casting platform insert w/cushions
• CE certification package (European Conformity)
• Hull color - Celestial Blue, Coastal Fog, Ocean Mist, or Sea Glass gelcoat
• Outrigger kit - 18-ft. (5.5 m) crank T-top mounted stainless
• steel outriggers w/carbon fiber poles
• Steering - Helm Master® EX w/Full Maneuverability
• Table - fiberglass bow table
• T-top mounted stainless steel outriggers
• T-top color - underside of fiberglass T-top (requires
• matching gelcoat hull color option)
• Underwater blue LED lighting

CANVAS OPTIONS

• Easy up bow shade (ivory mesh)
• Electrically retractable cockpit shade
• T-top side wing curtains (ivory)
